NAD C589
Artikelnummer: C589
Voorraad:ja
Prijs is inclusief BTW
€ 1.599,00
Omschrijving
- NAD’s Dynamic Digital Headroom (DDH) technology for improved clarity and dynamics
- QRONO d2a filtering for enhanced timing accuracy and musical realism
- Fully balanced DAC implementation with low noise and excellent dynamic range
- High-precision disc loader and laser pick-up for reliable playback
- Stereo RCA and balanced XLR analogue outputs
- Coaxial, optical, and AES/EBU digital outputs for system flexibility
- Rugged mechanical design ensures quiet, consistent disc handling
- Designed to integrate easily with high-performance audio systems
General Specifications |
|
| Output level | Line Out: 2.2 ±0.1V Balanced: 4.4 ±0.2V Digital Audio Out - Balanced: 2 - 3 Vp-p 110 ohms Digital Audio Out - Coaxial: 0.5 – 0.8 Vp-p 75 ohms |
|---|---|
| Frequency response | 20 Hz - 20 kHz (±0.3 dB) |
| Total harmonic distortion | ≤ 0.005% (1kHz, LPF 20kHz) |
| Signal/Noise ratio | ≥ 115 dB (1 kHz, A-weighted LPF 20 kHz Play) |
| Channel balance | 0.3 dB (0 dB 1 kHz) |
| Channel separation | ≥ 110 dB |
| De-emphasis | -3.73 to -5.33 dB (0 dB 1kHz, 5 kHz) -8.04 to -10.04 dB (0 dB 1 kHz, 16 kHz) |
| Linearity | -3 ±0.1 dB (0 dB 1 kHz at -3 dB) -6 ±0.2 dB (0 dB 1 kHz at -6 dB) -10 ±0.25 dB (0 dB 1 kHz at -10 dB) -20 ±0.25 dB (0dB 1 kHz at -20 dB) -60 ±0.5 dB (0dB 1 kHz at -60 dB) |
| Standby power | <0.5W |
| Idle power | ≤ 20 W |
